ST9824-4R 4CH IPC MNVR
Suntex IPC MNVR ST9824-4R
*Chip:Hisilicone
*System:Linux
*Compression format:H.264/H2.65 compressed mode
*Video input:4CH IPC 2M camera input (onvif protocol)
*Video output:HD x1;VGA x1;CVBS x1（M12 Aviation head 2 ports）*Audio input:NO
*Video resolution:1080P、720P、D1 optional
*Audio output: 1CH（M12 Aviation head 2interface)
*Storage:SD card Max 1TB and HDD Max 4TB.
*Playback: Support 4CH synchronous playback
*Network:4G/WIFI/GPS
*AI function: ADAS/DMS/BSD/APC
*Power input:DC:+8V ~ +36V
*Consumption:Normal less than 5W
*Working Temp.:-30℃-70℃
*Upload video and GPS track to CMS platform via 4G or WiFi
*Size: 17*17*6cm
*Weight: 1.2kg
