ST9824-AI 4CH AI MDVR

*CHIP:Hisilicon 3520D(V510)
*Compression Format:  H.264/H.265
*Camera input Resolution: AHD1080P/720P/CVBS
*Video Input:4CH M12-4 interface (+720P/1080P IPC cameras)
*Video Output: 3 CH (CVBS+VGA+HD)+RJ45

*Audio input:4CH M12 Aviation head
*Power Input:12V-36V
*Working Temp.:-30℃-70℃
*Size: 17*17*6cm
*Weight: 1.2kg

  • Overview
  • Related Products

AI MDVR 4CH HDD Vehicle video recorder

OS

Linux system Hisilicon solution

Network

4G/GPS/WIFI

AI function ADAS,DMS,BSD,APC
Storage Max 1TB SD Card*1+4TB HDD*1

Platform type Support

CMSV6/CMSV7 platform, JT808/JT1078 platform

ADAS

Lane departure detection, pedestrian and vehicle distance detection

DMS

Detection of unsafe driving behaviour habits such as driver fatigue, smoking, talking on the phone and covering up

BSD

Pedestrian detection in left and right blind zones

APC

AI intelligent People counting camera

Remote view CMSV6 platform on Mobile APP or PC

Fleet management

Support time-delay shutdown function

USB interface, you can use U disk backup video and upgrade and mouse connection

Two-level management of user password and administrator password

RS232,RS485 option

Support Power on logo,laser logo on shell

Application

Public Transportation,Trucks,Construction machinery,agricultural machinery,taxi,,Specialize vehicles


ST9824 详情-1.jpgST9824 详情-2.jpgST9824详情-3.jpgST9824详情-4.jpgST9824详情-5.jpgST9824详情-6.jpgST9824详情-7.jpgST9824详情-8.jpgST9824详情-9.jpgST9824详情-10.jpgST9824详情-11.jpgST9824详情-12.jpgST9824详情-13.jpgST9824详情-14.jpgST9824详情-15.jpgST9824详情-16.jpgST9824详情-17.jpgST9824详情-18.jpgST9824详情-20.jpgST9824详情-21(1).jpg

*CHIP:Hisilicon 3520D(V510)
*Compression Format: H.264/H.265
*Camera input Resolution: AHD1080P/720P/CVBS
*Video Input:4CH M12-4 interface (+720P/1080P IPC cameras)
*Video Output: 3 CH (CVBS+VGA+HD)+RJ45

*Audio input:4CH M12 Aviation head
*Power Input:12V-36V
*Working Temp.:-30℃-70℃
*Size: 17*17*6cm
*Weight: 1.2kg
